IGBT Module PIM

The PIM (Power Integrated Module) is a product that integrates a 3-phase inverter circuit, a diode bridge circuit, and a braking circuit into a single module, making it possible to create a compact design for the main circuit.
There are two main types of PIM depending on the motor capacity, namely the compact and lightweight Small PIM and the EconoPIM™.
We have prepared a product lineup to meet various requirements for the module terminal and printed circuit board connections, including the two types of soldered and solderless, and also products with different main terminal arrangements.

Series List
PIM (Built in converter and brake) EconoPIM™ X Series 650 V, 1200 V Class

7th-Generation X Series

*

Click on a product image to view the equivalent circuit diagram.

NEW New product

UP Update

UD Under development

Note

EconoPIM™ is a registered trademark of Infineon Technologies AG, Germany.

PIM (Built in converter and brake) EconoPIM™ V Series 600 V, 1200 V Class

6th-Generation V Series

*

Click on a product image to view the equivalent circuit diagram.

NEW New product

UP Update

UD Under development

Note

EconoPIM™ is a registered trademark of Infineon Technologies AG, Germany.
