Overseas High Efficiency Regulations Compliant Motors

Three-phase Induction Motors
  • Motor for EU
  • Motor for China
  • Motor for USA/Canada

Global Trend and Lineup

There has been an accelerating trend to suppress the usage of carbon dioxide (CO2) generating energy sources as a means of preventing worldwide global warming. Against this backdrop, a great change has occurred in the environment surrounding 3-phase induction motors (hereinafter "motors") since they occupy approximately 40 to 50% of the world's energy consumption. There is currently a rapid move taking place in many countries toward the adoption of regulation-compliant high-efficiency motors that meet national standards such as MEPS*.

MEPS: Minimum Energy Performance Standard

Overseas High Efficiency Regulations Compliant Motor Series

For EU

The Commission Regulation
Products certified to comply with the IEC60034-30-1:2014<IE3>

  • Compliant with the new Low Voltage Directive (2014/35/EU)!
For China

China Energy Efficiency Labeling Implementation Regulations
Products certified to comply with the GB18613-2012 <GB2 class>

  • Compliant with the new China RoHS Regulation!
  • Conform to CCC (China Compulsory Certification)!

(2P: 0.75 to 2.2 kW)

(4P: 0.75 kW)

For USA/Canada

Products certified to comply with the US Energy Independence and Security Act
NEMA MG1-12-12 <NEMA Premium (IE3)>/
Canada's Energy Efficiency Act
CSA C390 <Premium (IE3)>

  • Conforms to safety standards (UL/cUL recognition)!

Overview of Regulations of each Country

EU flag

Europe

China flag

China

USA flag

USA

Canada flag

Canada

Legal
name
Commission
Regulation (EC)
No.640/2009 (Europe)
Commission Regulation
Energy Efficiency
Labeling Implementation
Regulations
EISA
(Energy Independence and Security Act)
EEAct
(Energy Efficiency Act)
Regulation
effective date
From
January 1,
2015
From
January 1,
2017
From September 1,
2016
From September 1,
2017
From June 1, 2016 From January 1, 2011
Applicable
ranges
Individual motors and
motors integrated into equipment or machines
Efficiency
class
IE3 GB2 class
(IE3)
NEMA Premium
(IE3)
Premium
(IE3)
Compliance
standard
IEC60034-30-1:2014 GB18613-2012 NEMA MG1-12-12 CSA C390
Housing
structure
Applies to all
structure types.
Totally-enclosed
fan-cooled type
Totally-enclosed type,
open type
Totally-enclosed type,
open type
Output 7.5 kW or
larger to
375 kW or
smaller
0.75 kW or
larger to
375 kW or
smaller
7.5 kW or
larger to
375 kW or
smaller
0.75 kW or
larger to
375 kW or
smaller
1 to 500 HP
(0.75 to 373 kW)
1 to 200 HP
(0.75 to 150 kW)
1 to 200 HP
(0.75 to 150 kW)
Number
of poles
2, 4, 6P 2, 4, 6P 2, 4, 6, 8P 4, 6, 8P 2, 4, 6P
Voltage 1000 V or less 1000 V or less 600 V or less 600 V or less
Frequency 50 Hz or 50/60 Hz 50 Hz 60 Hz  60 Hz or 50/60 Hz
Characteristics Unspecified Design N Design A, B
(IEC Design N)
Design C
(IEC Design H)
Design A, B
(IEC Design N)
Design A, B, C
(IEC Design N, H)
Certification system
(Certification mark/
label)

(Self-declaration)

(Yes)
Safety certification
(Certification mark)

In addition to the above countries, there are countries where the rules and regulations are applied.
For details, please refer to the home page of the Japan Electrical Manufacturers' Association.
URL : http://www.jema-net.or.jp/
