Portable Ultrasonic Flowmeter <FSC>

Compact and handy

High accuracy ±1.0% of rate and fast response ≤ 1 s
A wide variety of detectors
Tolerant to bubbles
Battery-powered, for 12 hours
Data storage on SD card
USB port for connection with PC
Consumed energy calculation
Printer (option)
Flow velocity profile (option)

Movie

Portable type ultrasonic flowmeter

Movie

( 08:17 )

Catalog

Data Sheet

Manual

Consumed Energy Calculation

A function to obtain thermal energies exchanged via　fluid used in air-conditioning systems. The transmitter calculates the consumed thermal　energy based on the forward flow temperature,　the return flow temperature, and the flow rate.

Specifications

Fluid	Uniform liquid through which ultrasonic wave can propagate (water, distilled water, alcohol, etc.)
Pipe inner diameter	13–6000 mm (depends on detector)
Fluid temperature	-40°C to +200 °C (depends on detector)
Velocity	0 to ±32 m/s (minimum ±0.3 m/s)
Accuracy	±1.0% of rate (depends on flow rate)
Output cycle	1 s
Path	1 path, transit time method
Display	Color LCD with back light
Analog output	4–20 mA DC (1 point)
Analog input	4–20 mA DC/1–5 V DC (2 points)
Power supply voltage	Built-in battery, (12 hours of continuous operation)
Enclosure	IP64
Dimensions	210 × 120 × 65 mm
Weight	Approx. 1kg
SD card (option)	Data of 2-years worth can be stored in 512 MB card.
Serial communication	Data in SD card (instantaneous values, integrated values) can be transmitted to PC USB cable: maximum 3 m
Functions	Damping time constant (0–100 s) Instantaneous value display (10 digits) Various flow rate unit settable Total value display (10 digits) Various flow rate unit settable Consumed heat quantity computation Self diagnosis (battery voltage drop and received waveform from the sensor) Flash memory (parameters of pipe, fluid, sensor, etc) Number of registration sites: 32 Zero point adjustment (by setting/clearing zero) Graph view, waveform view Bi-directional flow measurement Low-flow cutoff (0–5 m/s)
Option	Printer: screen hard copy, periodic printing and logged data printing Detector for flow velocity profile measurement: displays flow velocity profile of instantaneous value and average value

Software Downloads
If you have the portable ultrasonic flowmeter FSC of the version 1 or 2, you have to update the flowmeter software to version 3.00. Check the model code. FSC□□□□■-□0□ ↑ If the 8th code is "1" or "2", the software update is required. FSC software updater: Ver 3.00 (zip/363.8KB) Update guide (En) (1.5MB) Windows 8.1/10 In addition to updating the FSC software to version 3, you have to carry out the followings: ⁃ Update the flowmeter FSC for Windows 8.1/10 FSC software (zip 200.9MB) Update guide (En) Update guide (Cn) ⁃ Update the parameter loader software for Windows 8.1/10 (Ver.3.000) Parameter loader software (2.0MB) Manual Windows 2000/XP/Vista You only have to update the FSC software to version 3. The parameter loader software is unchanged. Parameter loader software (msi/2.0 MB) Manual Notes: ⁃ After you update the flowmeter FSC for Windows 8.1/10, the flowmeter FSC will be no longer compatible with Windows 2000/XP/Vista. ⁃ The flowmeter FSC updated for Windows 8.1/10 do not work with the parameter loaders for the FSC version 1 and version 2. ⁃ Windows 7 PC is compatible with both versions of the parameter loader, version 2 and version 3.

Software Downloads

If you have the portable ultrasonic flowmeter FSC of the version 1 or 2, you have to update the flowmeter software to version 3.00.
Check the model code.

FSC□□□□■-□0□
↑
If the 8th code is "1" or "2", the software update is required.

Windows 8.1/10

In addition to updating the FSC software to version 3, you have to carry out the followings:

⁃ Update the flowmeter FSC for Windows 8.1/10

⁃ Update the parameter loader software for Windows 8.1/10 (Ver.3.000)

Windows 2000/XP/Vista

You only have to update the FSC software to version 3. The parameter loader software is unchanged.

Notes:

⁃ After you update the flowmeter FSC for Windows 8.1/10, the flowmeter FSC will be no longer compatible
with Windows 2000/XP/Vista.

⁃ The flowmeter FSC updated for Windows 8.1/10 do not work with the parameter loaders for the FSC
version 1 and version 2.

⁃ Windows 7 PC is compatible with both versions of the parameter loader, version 2 and version 3.
