| Category |
Name |
Applicable |
Specifications |
Type |
| Options |
For sequence I/O (between host and amplifier) |
Sequence I/O cable |
For VS, LS, and VV servo amplifiers |
3m (bare wires on one side) |
WSC-D36P03 |
| Sequence I/O connector*1 |
For VS, LS, and VV servo amplifiers |
1 set |
WSK-D36P |
| For safety equipment |
Safety equipment cable |
Amplifier side: all capacities |
1m (bare wires on one side) |
WSC-D08P01 |
| For motor power (between amplifier and motor) |
Motor power cable |
GYS: 0.05 to 0.75kW GYB: 0.2 to 0.75kW
(Lead wire type) |
2m (bare wires on one side) |
WSC-M04P02-E |
| 5m (bare wires on one side) |
WSC-M04P05-E |
| 10m (bare wires on one side) |
WSC-M04P10-E |
| 20m (bare wires on one side) |
WSC-M04P20-E |
GYB: 0.2 to 0.75kW
(Connector type) |
2m (bare wires on one side) |
WSC-M04P02-K |
| 5m (bare wires on one side) |
WSC-M04P05-K |
| 10m (bare wires on one side) |
WSC-M04P10-K |
| 20m (bare wires on one side) |
WSC-M04P20-K |
GYS: 0.05 to 0.75kW GYB: 0.2 to 0.75kW
(Lead wire type) |
2m (bare wires on one side) |
WSC-M02P02-E |
| 5m (bare wires on one side) |
WSC-M02P05-E |
| 10m (bare wires on one side) |
WSC-M02P10-E |
| 20m (bare wires on one side) |
WSC-M02P20-E |
GYB: 0.2 to 0.75kW
(Connector type) |
2m (bare wires on one side) |
WSC-M02P02-K |
| 5m (bare wires on one side) |
WSC-M02P05-K |
| 10m (bare wires on one side) |
WSC-M02P10-K |
| 20m (bare wires on one side) |
WSC-M02P20-K |
| Motor power connector*1 |
GYS/GYB: 0.05 to 0.75kW*2 |
1 set |
WSK-M04P-E |
| GYS: 1.0 to 2.0kW |
1 set |
WSK-M04P-CA |
| GYS: 3.0 to 5.0kW |
1 set |
WSK-M04P-CB |
| GYG: 0.85 to 2.0kW |
1 set |
WSK-M04P-CC |
| GYS/GYB: 0.05 to 0.75kW*2 |
1 set |
WSK-M02P-E |
| GYS: 1.0 to 2.0kW |
1 set |
WSK-M06P-CA |
| GYS: 3.0 to 5.0kW |
1 set |
WSK-M06P-CB |
| GYG: 0.85 to 2.0kW |
1 set |
WSK-M06P-CC |
| For encoder (between amplifier and motor) |
Encoder cable |
GYS: 0.05 to 0.75kW GYB: 0.2 to 0.75kW
(Lead wire type) |
2m |
WSC-P06P02-E |
| 5m |
WSC-P06P05-E |
| 10m |
WSC-P06P10-E |
| 20m |
WSC-P06P20-E |
GYB: 0.2 to 0.75kW
(Connector type) |
2m |
WSC-P06P02-K |
| 5m |
WSC-P06P05-K |
| 10m |
WSC-P06P10-K |
| 20m |
WSC-P06P20-K |
| GYS: 1.0 to 5.0kW |
5m |
WSC-P06P05-C |
| 10m |
WSC-P06P10-C |
| 20m |
WSC-P06P20-C |
| GYG: 0.85 to 2.0kW |
5m |
WSC-P06P05-J |
| 10m |
WSC-P06P10-J |
| 20m |
WSC-P06P20-J |
| Encoder connector*1 |
Amplifier side: all capacities |
1 set |
WSK-P06P-M |
| GYS/GYB: 0.05 to 0.75kW*2 |
1 set |
WSK-P09P-D |
| GYS: 1.0 to 5.0kW |
1 set |
WSK-P06P-C |
| GYG: 0.85 to 2.0kW |
1 set |
WSK-P10P-J |
| Junction cable for encoder with battery |
For VV and VC servo amplifiers |
0.3m |
WSC-P06P0R3-BG |
| Encoder cable with a battery (1) |
For VV and VC servo amplifiers GYS/GYB
Lead wire connection specifications
0.75kW or less |
2m |
WSC-P06P02-BE |
| 5m |
WSC-P06P05-BE |
| 10m |
WSC-P06P10-BE |
| 20m |
WSC-P06P20-BE |
| Encoder cable with a battery (2) |
For VV and VC servo amplifiers GYB
Connector connection specification
0.75kW or less |
2m |
WSC-P06P02-BK |
| 5m |
WSC-P06P05-BK |
| 10m |
WSC-P06P10-BK |
| 20m |
WSC-P06P20-BK |
| Encoder cable with a battery (3) |
For VV and VC servo amplifiers GYS
1.0 [kW] or more |
2m |
WSC-P06P02-BC |
| 5m |
WSC-P06P05-BC |
| 10m |
WSC-P06P10-BC |
| 20m |
WSC-P06P20-BC |
| Encoder cable with a battery (4) |
For VV and VC servo amplifiers GYG |
2m |
WSC-P06P02-BJ |
| 5m |
WSC-P06P05-BJ |
| 10m |
WSC-P06P10-BJ |
| 20m |
WSC-P06P20-BJ |
| Battery case kit for encoder cable |
For VV and VC servo amplifiers |
1 set |
WSB-BC |
| For SX bus |
SX bus cable |
For VS and LS servo amplifiers |
0.3m |
NP1C-P3 |
| 0.6m |
NP1C-P6 |
| 0.8m |
NP1C-P8 |
| 2m |
NP1C-02 |
| 5m |
NP1C-05 |
| 10m |
NP1C-10 |
| 15m |
NP1C-15 |
| 25m |
NP1C-25 |
| ABS backup battery |
Battery and mounting case set for VS servo amplifier * With mounting case |
1 set |
WSB-SC |
| Battery * Replacement battery only |
1 piece |
WSB-S |
| External regenerative resistor |
GYS, GYB: 0.05 to 0.4kW |
1 piece |
WSR-401 |
| GYS, GYB: 0.75 to 1.5kW, GYG: 0.85, 1.0kW |
1 piece |
WSR-152 |
| GYS: 2.0 to 3.0kW GYG: 1.3 to 2.0kW |
1 piece |
DB11-2 |
| GYS: 4.0 to 5.0kW |
1 piece |
DB22-2 |
| For PC loader connection |
RS232C-RS-485 Conversion adapter |
For connection of VV type servo amplifier’s RS-485 port |
- |
NW0H-CNV |
| Cable |
2m |
WSC-PCL |
