| Name |
Specifications |
Type |
| For main circuit of amplifier |
Power supply connector (for amplifier control power and main power supply) |
0.05 to 1.5kW (to 1.0kW with GYG) |
1 set |
WSK-S05P-E |
| DC circuit connector (wiring of external regenerative resistor, DC reactor, DC link circuit) *1 |
0.05 to 1.5kW (to 1.0kW with GYG) |
1 set |
WSK-R06P-E |
| Motor power connector (wiring of main motor power) |
0.05 to 1.5kW (to 1.0kW with GYG) |
1 set |
WSK-M03P-E |
For sequence I/O
(between host and amplifier) |
Sequence I/O cable |
All capacities |
3m (bare wires on one side) |
WSC-D36P03 |
| Sequence I/O connector kit *4 |
Amplifier side : All capacities |
1 set |
WSK-D36P |
For encoder
(between amplifier and motor) |
Encoder cable |
3000r/min for 0.05 to 0.75kW |
2m (connector at both ends) |
WSC-P06P02-E |
| 5m (connector at both ends) |
WSC-P06P05-E |
| 10m (connector at both ends) |
WSC-P06P10-E |
| 20m (connector at both ends) |
WSC-P06P20-E |
3000r/min for 1.0 to 5.0kW
2000r/min for 0.5 to 2.0kW
1500r/min for 0.5 to 1.3kW |
5m (connector at both ends) |
WSC-P06P05-C |
| 10m (connector at both ends) |
WSC-P06P10-C |
| 20m (connector at both ends) |
WSC-P06P20-C |
| Encoder connector kit *4 |
Amplifier side : All capacities |
1 set |
WSK-P06P-M |
| Motor side : 0.05 to 0.75kW |
1 set |
WSK-P09P-D |
| Motor side : 0.5 to 5.0kW |
1 set |
WSK-P06P-C |
| For motor power (between amplifier and motor) |
Motor power cable |
For main motor power *2 |
GYS, GYC, GYB : 0.05 to 0.75kW |
2m (bare wires on one side) |
WSC-M04P02-E |
| 5m (bare wires on one side) |
WSC-M04P05-E |
| 10m (bare wires on one side) |
WSC-M04P10-E |
| 20m (bare wires on one side) |
WSC-M04P20-E |
| For brake power *3 |
GYS, GYC, GYB : 0.05 to 0.75kW |
2m (bare wires on one side) |
WSC-M02P02-E |
| 5m (bare wires on one side) |
WSC-M02P05-E |
| 10m (bare wires on one side) |
WSC-M02P10-E |
| 20m (bare wires on one side) |
WSC-M02P20-E |
| Motor power connector kit |
For main motor power *4 |
Motor side : GYS, GYC, GYB 0.05 to 0.75kW |
1 set |
WSK-M04P-E |
| For brake power *4 |
Motor side : GYS, GYC, GYB 0.05 to 0.75kW |
1 set |
WSK-M02P-E |
| For main motor power *4 |
Motor side : GYS 1.0 to 2.0kW GYG 0.5 to 2.0kW |
1 set |
WSK-M04P-CA |
| Motor side : GYS 3.0 to 5.0kW GYC 1.0 to 2.0kW |
1 set |
WSK-M04P-CB |
| For main motor power + brake power *4 |
Motor side : GYS 1.0 to 2.0kW GYG 0.5 to 2.0kW |
1 set |
WSK-M06P-CA |
| Motor side : GYS 3.0 to 5.0kW GYC 1.0 to 2.0kW |
1 set |
WSK-M06P-CB |
| For SX bus |
SX bus cable |
For VS and LS type servo amplifiers |
0.3m (connector at both ends) |
NP1C-P3 |
| 0.6m (connector at both ends) |
NP1C-P6 |
| 0.8m (connector at both ends) |
NP1C-P8 |
| 2m (connector at both ends) |
NP1C-02 |
| 5m (connector at both ends) |
NP1C-05 |
| 10m (connector at both ends) |
NP1C-10 |
| 15m (connector at both ends) |
NP1C-15 |
| 25m (connector at both ends) |
NP1C-25 |
