Brake |
Mounting |
Output shaft rotor
speed
[min-1] |
50Hz |
210 |
150 |
100 |
75 |
60 |
50 |
37.5 |
33.3 |
30 |
25 |
18.8 |
15 |
12.5 |
9.4 |
7.5 |
6.3 |
60 Hz |
250 |
180 |
120 |
90 |
72 |
60 |
45 |
40 |
36 |
30 |
22.5 |
18 |
15 |
11.3 |
9 |
7.5 |
![](/products/drives_inverters/motor/product_series/map_01.webp) |
7 |
10 |
15 |
20 |
25 |
30 |
40 |
45 |
50 |
60 |
80 |
100 |
120 |
160 |
200 |
240 |
Without Brake |
Face
mount |
Standard efficiency |
0.1 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
0.2 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
0.4 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
Premium
efficiency |
0.75 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
|
|
1.5 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
|
|
|
2.2 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
|
|
|
With Brake |
Face
mount |
Standard efficiency |
0.1 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
0.2 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
0.4 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
Premium
efficiency |
0.75 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
|
|
1.5 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
|
|
|
2.2 |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
○ |
|
|
|
![](/products/drives_inverters/motor/product_series/map_03.webp)
One-week production product
(Note) For Semi-standard specification, two-week production product
![](/godata/products/motor/geared_mhx/box/img/map_04.jpg)
Production not possible
This map is designed for Japan.
Products conforming to the EC Directive for the European market (with the CE marking) only support the semistandard specification (output: 0.2 to 7.5 kW).
|
Standard efficiency |
Premium efficiency |
Without Brake |
With Brake |
Without Brake |
With Brake |
0.1 kW
0.2 kW
0.4 kW |
0.1 kW
0.2 kW
0.4 kW |
0.75 kW
1.5 kW |
2.2kW |
0.75 kW
1.5 kW |
2.2kW |
Motor |
Housing structure |
Totally-enclosed self-cooled type |
Totally-enclosed fan-cooled type |
Number of poles |
4P |
4P |
Number of phases |
Three-phase |
Three-phase |
Rated voltage |
200 / |
200
220 |
V |
or |
380
400 /
415 |
380
400
440
460 |
V |
|
200 / |
200
220 |
V |
or |
400 / |
400
440 |
V |
|
Rated frequency |
50 /60 Hz |
50 /60 Hz |
Time rating |
S1 (continuous) |
S1 (continuous) |
Thermal class |
130 (B) |
155 (F) |
Compliance |
Applicable |
JIS C 4034-1 |
JIS C 4213 |
Efficiency |
ー |
JIS C 4034-30:2011 |
Protection rating |
IP44 |
IP44 |
Terminal |
Position |
Bottom |
Bottom |
Output direction |
In anti-load-side direction |
In anti-load-side
direction |
Right direction |
In anti-load-side
direction |
Right direction |
Starting method |
Direct input |
Direct input |
Brake |
Braking method |
ー |
DC non-excitation actuated type |
ー |
DC non-excitation actuated type |
Power supply |
ー |
Note) Input: 200 AC / 200 to 220 V |
ー |
Note) Input: 200 AC / 200 to 220 V |
Braking torque |
ー |
150 / 180% |
ー |
150 / 180% |
Protection rating |
IP20 |
IP20 |
Speed reducer |
Speed reducing system |
Orthogonal axes |
Orthogonal axes |
Lubrication method |
Grease lubrication (Dedicated grease refilling) |
Grease lubrication (Dedicated grease refilling) |
Major parts and materials |
Casing: Aluminum die-cast or cast iron
Gear: Chromium molybdenum steel |
Casing: Aluminum die-cast or cast iron
Gear: Chromium molybdenum steel |
Surrounding
environment |
Installation location |
Indoor |
Indoor |
Ambient temperature and humidity |
Ambient temperature: -10°C to +40°C
Humidity: 95 RH% max. (ensuring no condensation) |
Ambient temperature: -10°C to +40°C
Humidity: 95 RH% max. (ensuring no condensation) |
Altitude |
1,000 m max. |
1,000 m max. |
Atmosphere |
No corrosive or explosive gas or steam |
No corrosive or explosive gas or steam |
Installation angle |
Mounting direction flexibility |
Mounting direction flexibility |
Direction of rotation |
![](/godata/products/motor/geared_mhx/box/img/mhx_01.gif) |
![](/godata/products/motor/geared_mhx/box/img/mhx_02.gif) |
Color of coating |
Silver |
Silver |
-
Note
-
With regard to 400 V class models having a brake, it is necessary to install a single-winding transformer of at least 100 VA (200 V input) on the primary side of the power module (brake power supply).
1. Terminal Box Type Change
|
Standard efficiency |
Premium efficiency |
0.1kW |
0.2kW |
0.4kW |
0.75 kW |
1.5kW |
2.2kW |
Without Brake |
Standard |
Low profile plastic |
Steel plate |
Semi-standard |
Steel strip* |
ー |
With Brake |
Standard |
Low profile plastic (PM integrated) |
Steel strip
(PM included) |
Semi-standard |
Steel strip (PM included) |
ー |
-
Note
-
For models without a brake having the * sign written above, as well as leg mounting types and models with an output of 0.1 to 0.4 kW, a portion of the standard specification is supported.
2. Possible to change to a 90° pitch for the terminal box mounting position.
3. Outdoor specification (Without Brake)
-
Note
-
Consult with your nearest sales department regarding compatibility with outdoor types having a brake.
4. EC Directive (CE marking)
-
Note
-
This corresponds to a steel strip terminal box for types having no brake. (Output 0.1 to 0.4 kW)
