Servo Systems
FALDIC-β

Jan. 9. 2019
Information on Discontinuation of FALDIC-β servo amplifiers

Thank you for your many years of loyal patronage.
Our FALDIC-β series servo amplifiers were discontinued in December 2018.
As replacement models for future equipment updates or new applications, we recommend the servo amplifiers in our ALPHA 7 series, ALPHA 5 series or ALPHA 5 Smart series.

List of models

Servomotor

Specifications Part code Model type
Motor type Voltage Model Rated output
GYS series servomotor
(slim type)		 100V/200V Standard motor 0.05kW GYS1061 GYS500DC1-C8B
200V Standard motor 0.1kW GYS1062 GYS101DC1-CB
0.2kW GYS1063 GYS201DC1-CA
0.4kW GYS1064 GYS401DC1-CA
0.75kW GYS1065 GYS751DC1-CA
100V/200V Motor with a brake 0.05kW GYS1081 GYS500DC1-C8B-B
200V Motor with a brake 0.1kW GYS1082 GYS101DC1-CB-B
0.2kW GYS1083 GYS201DC1-CA-B
0.4kW GYS1084 GYS401DC1-CA-B
0.75kW GYS1085 GYS751DC1-CA-B
100V Standard motor 0.1kW GYS1102 GYS101DC1-C6B
0.2kW GYS1103 GYS201DC1-C6B
Motor with a brake 0.1kW GYS1112 GYS101DC1-C6B-B
0.2kW GYS1113 GYS201DC1-C6B-B
GYC series servomotor
(cubic type)		 200V Standard motor 0.1kW GYC1040 GYC101DC1-CA
0.2kW GYC1041 GYC201DC1-CA
0.4kW GYC1042 GYC401DC1-CA
0.75kW GYC1043 GYC751DC1-CA
Motor with a brake 0.1kW GYC1050 GYC101DC1-CA-B
0.2kW GYC1051 GYC201DC1-CA-B
0.4kW GYC1052 GYC401DC1-CA-B
0.75kW GYC1053 GYC751DC1-CA-B

Gear head

Applied motor Gear ratio Applied motor capacity Part code Model type
GYS series servomotor
(slim type)		 1/9 0.05kW GYN101S GYN500SAG-G09
0.1kW GYN102S GYN101SAG-G09
0.2kW GYN103S GYN201SAG-G09
0.4kW GYN104S GYN401SAG-G09
0.75kW GYN105S GYN751SAG-G09
1/25 0.05kW GYN121S GYN500SAG-G25
0.1kW GYN122S GYN101SAG-G25
0.2kW GYN123S GYN201SAG-G25
0.4kW GYN124S GYN401SAG-G25
0.75kW GYN125S GYN751SAG-G25
GYC series servomotor
(cubic type)		 1/9 0.1kW GYN100C GYN101CAG-G09
0.2kW GYN101C GYN201CAG-G09
0.4kW GYN102C GYN401CAG-G09
0.75kW GYN103C GYN751CAG-G09
1/25 0.1kW GYN120C GYN101CAG-G25
0.2kW GYN121C GYN201CAG-G25
0.4kW GYN122C GYN401CAG-G25
0.75kW GYN123C GYN751CAG-G25

Servo amplifier

Input voltage Applied motor capacity Part code Model type
3-phase 200V 0.05kW RYB1001 RYB500S3-VBC
0.1kW RYB1002 RYB101S3-VBC
0.2kW RYB1003 RYB201S3-VBC
0.4kW RYB1004 RYB401S3-VBC
0.75kW RYB1005 RYB751S3-VBC
Single-phase 100V 0.05kW RYB3001 RYB500S3-VBC6
0.1kW RYB3002 RYB101S3-VBC6
0.2kW RYB3003 RYB201S3-VBC6

Options

Part name Part code Model type
Control signal input/output cable Common to the all models (with 26 pin connector) 3 m (connector at one end) RYWS801 WSC-D26P03
Encoder cable Common to the all models 5 m (connector at both ends) RYWS803 WSC-P06P05
10 m (connector at both ends) RYWS804 WSC-P06P10
20 m (connector at both ends) RYWS805 WSC-P06P20
Power cable for motor wiring Motor without a brake 5 m (connector at both ends) RYWS812 WSC-M04P05-B
10 m (connector at both ends) RYWS813 WSC-M04P10-B
20 m (connector at both ends) RYWS814 WSC-M04P20-B
Motor with a brake 5 m (connector at both ends) RYWS818 WSC-M06P05-B
10 m (connector at both ends) RYWS819 WSC-M06P10-B
20 m (connector at both ends) RYWS820 WSC-M06P20-B
Power cable for power supply unit Between power input and amplifier (common to the all models) 3 m (connector at one end) RYWS824 WSC-S03P03-B
Connector kit for control signal input/output 26 pin connector - RYWS021 WSK-D26P
Connector kit for encoder wiring Amplifier (common to the all models) - RYWS023 WSK-P06P-M
Motor (common to the all models) - RYWS024 WSK-P06P-F
Power cable connector kit for motor wiring Amplifier (common to the all models) - RYWS034 WSK-M03P-B
Motor (without motor, 4 pin) - RYWS026 WSK-M04P
Motor (with motor, 6 pin) - RYWS028 WSK-M06P
Power cable connector kit for power supply unit Amplifier (common to the all models) - RYWS033 WSK-S03P-B
Power cable connector kit for external regenerative resistor Amplifier (common to the all models) - RYWS035 WSK-R03P-B
External regenerative resistor Max. 0.4 kW *1 - RYWS010 WSR-401
0.75 kW *1 - RYWS011 WSR-751
Max. 0.4 kW (slim type) - RYWS013 WSR-401-T
0.75 kW (slim type) - RYWS014 WSR-751-T
Personal computer loader (CD) Common to the all ß models - RYWS004 WSL-PC-B
PC loader converter Common to the all ß models - RYWS830 WST-232C
PC loader cable Common to the all ß models - RYWS005 WSC-PCL

*1)

When using the resistor WSR-401 or WSR-751, order the power cable connector kit for external regenerative resistor WSK-R03P-B.
